SCHNEIDER ELECTRIC Xantrex CM/R-50 Digital Remote Panel CM/R-50

SCHNEIDER ELECTRIC Xantrex CM/R-50 Digital Remote Panel CM/R-50

31,343.90 Exc VAT

  • The Xantrex CM/R-50 remote display provides a digital
  • display for monitoring the C-Series controller’s operation.
  • The CM/R-50 is intended for remote applications and provides
  • a digital display of current, voltage, amperage, and amp hours.
    The CM/R-50 features a back-lit LCD to show current, voltage,
  •  amperage, resettable amp hours and total amp hours,
  • an Amp-hour reset button (also used to illuminate or dim
  • the display), and a multi-color LED indicator for monitoring
  • the operating status of the C Series controller. A color-coded
  •  label is included on the cover or the controller explaining the
  • status LED’s indications.
    The CM/R-50 plugs directly into the Digital Meter Display Port of the C35,
  • C40 or C60 Charge Controllers with the included 50-foot communications cable.
  •  The CM/R-50 can be installed with cable runs of up to 1,000 feet by using a
  • six-conductor telephone cable with modular-type connectors.
    The CM/R-50 can be permanently installed in a wall or cabinet and can be
  •  flush mounted or surface mounted using a double-gang, non-metallic outlet box.
Availability: 3 in stock SKU: CM/R-50 Category:
  • Description
  • Additional information
  • Reviews (0)

Description

  • Product Features

    • LCD panel shows current, voltage, amperage, resettable amp hours and total amp hours
    • Amp-hour reset button
    • Adjustable backlight
    • LED system status indicators
    • 50′ (15 m) communications cable for remote mounting
  • Compatible Models

    • C35 PWM Charge Controller
    • C40 PWM Charge Controller
    • C60 PWM Charge Controller
