Schneider Electric Battery Fuse Disconnect

Description

Conext Battery Solar Combiner Box

Combine, connect and disconnect
Conext inverter/chargers with battery bank

The Conext™ Battery Fuse Combiner
Box 250 combines up to three Conext XW+ inverter/chargers with one battery
bank using a single battery pole disconnect method and provides fuse protection
for cables, batteries and inverter/chargers. Two Battery Fuse Combiner Box 250s
can be configured side-by-side to accommodate dual battery pole disconnection
requirements. A smaller, more compact Battery Fuse Combiner Box 160 is
available for battery side application with Conext MPPT Solar Charge
Controllers.

Part
number

• Battery Fuse Combiner Box 160 – 865-1030-01
• Battery Fuse Combiner Box 250 – 865-1031-01

Overview

Why
Choose Conext Battery Fuse Combiner Box

Higher return on investment

• One low cost device to combine up to three Conext
  inverter chargers with one battery bank
• Standardized repeatable and cost effective installation
  method

Flexible

• Single or dual pole battery disconnection for Conext XW
  and SW inverter chargers
• Single or dual pole battery disconnection for Conext
  MPPT Solar Charge Controllers

Easy to service

• Clear plastic window allows visual no-touch inspection
  of fuses
• Access holes for volt meter probes allow for testing
  without interrupting system
• Lockout accepts lead seal to guard against unauthorized
  access

Easy to install

• Wall-mount or flush-mount
• Lug nut cable connections
