Pylontech Lithium-ion Batteries US2000 Series

HOT

Pylontech Lithium-ion Batteries US2000 Series

This is an ideal solution for residential storage applications, with standard 48V/50AH specification, up to 90% usable capacity and 6,000 cycle-life warranty.

Pylontech Spec Sheet Download

Pylontech Compatibility Sheet Download

  • Description
  • Product Specifications
  • Additional information
  • Reviews (0)

Description

  • Vertical industry integration ensures more than 6000 cycles with 90% DoD
  • Compact and fashionable design fits in your sweet home environment
  • Deliver up to 5KW with single module (2.4KWh)
  • Modular design gives the end customers the power of choice of capacity
  • Compatible with most of the available Hybrid inverters
  • Simple buckle fixing minimize the installation time and cost
  • Safety Cert.TüV CE UN38.3



SPECIFICATION BASICPARAMETERS US2000
Nominal Nominal Voltage(V)
Nominal Capacity(Wh)
Usable Capacity (Wh)
48
2400
2200
Physical Dimension (mm)
Weight (Kg)
440*410*89
24
Electrical Discharge Voltage (V)
Charge Voltage (V)
Charge/Discharge Current (A)
45 ~ 53.5
52.5 ~ 53.5
100(Peak@15s)
Others Communication
Charging Temperature
Discharging Temperature
Shelf Temperature
Certification
Design life
Cycle Life
RS485,CAN
0℃~50℃
-10℃~50℃
-20℃~60℃
TüV / CE / UN38.3
10+ Years(25℃/77℉)
>6000, 25℃

Additional information

Brand

Pylontech
